    Liste der D|I|G|I|T|A|L (DEC) Module: M001 - M499:
    Diese Listen dienen zur Information, welche Module der Hersteller produziert hat. Die Anzahl unserer lieferbaren Module werden in der Spalte "Lagerbestand" dokumentiert.

    These lists are only informations, which parts were producted. Our available parts are shown in the row "Lagerbestand".
    M-Series Control Moduls

    Futher informations see D|I|G|I|T|A|L Control handbook 1969, FLIP CHIP, DIGITAL EQUIPMENT CORPORATION

    These parts are used in PDP-8/L, PDP-8/I, PDP-9/L, PDP-9/I, PDP10, PDP11, PDP12, PDP14 and PDP15
    Modulname Bezeichnung System options QBUS Unibus Lager- bestand Bild
    M002 15 Loads, Logic "1" Source (for PC15) PC15   3 DEC Modul M002, 15 Loads, Logic "1" Source (for PC15), (1523738 Byte)
    M040 Solenoid Driver     1 DEC Modul M040, Solenoid Driver, (1607172 Byte), von oben
    M044 4 x 100 mA Solenoid driver     0
    M050 50mA indicator and relay driver     0
    M051 Level converter     0
    M060 Solenoid Driver     0
    M100 Bus data interface     1 DEC Modul M100, Bus data interface, von oben (1656012 Byte)
    M101 Bus data interface   U 2 DEC Modul M101 Bus data interface, von oben
    M102 Device selector (for PC15 (PDP8 I/L)) PC15 U 0
    M103 Device selector (for PC15 (PDP8 I/L)) PC15 U 5 DEC Modul Device selector (for PC15 (PDP8 I/L)) M103, von oben
    M104 I/O Multiplexer (for PC15 in PDP-15) PC15 U 0
    M105 Device selector for PDP, Address selector TM11 U 2 DEC Modul Device selector for PDP, Address selector M105 (52905 Byte)
    M107 C Device selector PDP-8, Non Omnibus PDP-11 NO 1 DIGITAL (DEC) Modul M107, Device selector for PDP-8
    M108 flag module PDP-11 U 0
    M109 PDP-11 device selector with jumpers, bits 13-17 PDP-11 U 0
    M111 Inverter (x16) (for PC15) RS09 U 0
    M112 NOR gate (x10) TM11 U 1 DIGITAL (DEC) Modul M112, NOR gate (x10), (18568 Byte)
    M113 2-input NAND gates (x10) (for PC15) TM11 U 25 DIGITAL (DEC) Modul M113 ,2-input NAND gates (x10) (for PC15), (31852 Byte)
    M115 3-input NAND gates (x8) TM11 U 3 DIGITAL (DEC) Modul M115, 3-input NAND gates (x8) (951342 Byte)
    M116 NORGATE, 6 QUAD   U 0
    M117 4-input NAND gates (x6)(for PC15) TM11 U 3 M117.JPG (1227876 Byte)
    M119 8-input NAND gates (x3)   U 0
    M121 AND-NOR gates (x6) TM11 U 0
    M126 2x2 AND-NOR gates (x6)   U 0
    M127 2-2-2-3 AND/NOR gates TM11, KE15 U 0
    M128 AND-NOR gates (x4)   U 0
    M130 Parity checkers and gates   U 0
    M133 NAND gates TM11, KE15 U 0
    M135 3 INPUT NAND-GATE   U 1 DIGITAL (DEC) Modul M135.jpg (18663 Byte)
    M137 high speed 4-input power NAND Gates   U 0
    M139 8-input NAND gate (x3) (pinout different from M119)   U 0
    M139 8-input NAND gate (x3) (pinout different from M119)   U 0
    M141 AND/NOR gates   U 0
    M142 4 Bit adder   U 0
    M145 Address selector   U 0
    M143 3-input NAND gates (x7)   U 0
    M147 4-input NAND gates (x5)   U 0
    M149 9 x 2 NAND wired OR matrix, Indicator driver (for PC15) TM11/ PC15 U 0
    M151 Decoders (x2)   U 0
    M152 Decoders (x2)   U 0
    M155 4-line to 16-line Decoder   U 0
    M159 Arithmetric/logic unit   U 0
    M160 AND/NOR Gate module   U 2 DIGITAL (DEC) Modul M160,AND/NOR Gate module (1803349 Byte)
    M161 Binary to Octal/Decimal Decoder   U 0
    M162 Parity circuit   U 0
    M163 DUAL BCD Decoder, Binary to decimal decoder (x2) TM11 U 0
    M165 Buffers (x8)   U 0
    M166 1 gate (incrementer)   U 0
    M167 Compares two 8-bit words ( <, =, > )    U 0
    M168 12-bit magnitude comparator    U 0
    M169 Gating Module   U 0
    M170 8 wide AND-NOR   U 0
    M171 2-2-2-3 AND-NOR gates (x3)   U 0
    M172 2x9 data mixer   U 0
    M173 AND gates (x10)   U 0
    M174 4x9 data mixer   U 0
    M175 3-input AND gates (x7)   U 0
    M177 4-input AND gates (x5)   U 0
    M178 8x6 data mixer   U 0
    M181 2-2-2-3 AND-OR gates   U 0
    M191 ALU Look-Ahead Logic   U 0
    M200 Drive roller CR04 U 0
    M202 J-K flip flop module TM11 U 2 DEC Modul M202, J-K flip flop module, von oben
    M203 eight Set-Reset flip flop module TM11 U 0
    M204 General purpose buffer and counter module TM11 U 0
    M205 five -"D" FLIP FLOPS TM11 U 0
    M206 Six General purpose flip-flops   U 16 DIGITAL (DEC) Modul M206.JPG (1445748 Byte)
    M207 Six General purpose flip-flops   U 0
    M208 8 BIT BUFFER/SHIFT REGISTER   U 0
    M211 Binary up/down counter (6 bits wide)   U 0
    M212 6-Bit L-R Shift Register   U 0
    M213 BCD up/down counter   U 0
    M216 Six flop-flops TM11, KE15 U 0
    M217 Clock Register   U 0
    M220 Major registers   U 4 DEC Modul M220 Major registers, von oben
    M221 Main Register (PDP-12 specific)   U 0
    M222 LINCtape Register   U 0
    M224 11/20 8-bits with data paths module, 2 latches, adder.   0
    M225 11/20 registers module (processor memory).16 bits x 16 bits   U 0
    M230 Binary to BCD and BCD to binary converter   U 0
    M234 3 8-bit registers, adder & L/R shift   U 0
    M236 12-bit binary up/down counter   U 1 DEC Modul M236 12-bit binary up/down counter, von oben
    M237 3-digit BCD up/down counter   U 0
    M238 Dual 4-bit binary synchronous up/down counter   U 0
    M239 3 4-Bit Counter registers, (8291s) or 74197, parallel load TM11  U 0
    M241 Six type D flip-flips   U 0
    M243 8 type D flip-flops   U 0
    M244 6 Ckts, Each 3 input Mux with latch, non-inverting   U 0
    M245 Dual 4-bit shift register   U 0
    M246 5 D flip-flops   U 1
    M247 Console switch flip-flops   U 0
    M248 Dual 4-bit multipurpose shift register   U 1 DEC Modul M248, Dual 4-bit multipurpose shift register, (17291 Byte)
    M250 4 bit x 16 word memory   U 0
    M253 12 bit 16 word memory   U 0
    M259 Associative memory, 2x8, shift register capability KT11  U 0
    M260 16 word x 12 bit Associative memory cell   U 0
    M302 Dual delay multivibrator (PC15) RS09,
    VT15
    U 4 M302.JPG (999669 Byte)
    M304 One-shot delay (PC15) TM11 U 0
    M306 Integrating one-shot   U 0
    M307 Integrating one-shot module TU56 U 0
    M308 Integrating one-shot   U 0
    M310 Delay line   U 10 DEC Modul M310, Delay line (1303705 Byte)
    M311 Delay (for PC15)   U 0
    M321 Tapped delay line   U 0
    M360 Variable delay   U 0
    M362 Latched register driver   U 0
    M363 Variable delay   U 0
    M401 Variable clock VT15 U 2 DEC Modul M401, Variable clock, (20355 Byte)
    M403 RC Multivibrator clock   U 0
    M404 Crystal clock   U 0
    M405 Crystal clock DC01 U 0
    M410 Reed clock   U 1 DEC Modul M410, Reed clock (1376557 Byte)
    M452 Variable (TTY) clock (for PC15) PC15  U 0
    M454 Crystal clock with simultaneous outputs of 28.8, 19.2, 9.6, 4.8, 2.4, 1.760 KHz, (for DC11-A, DP11-A) DC11-A U 0
